RELIABLY WATERPROOFED
Exterior waterproofing of buildings
Basements are often converted to obtain additional living space. Whether you want to create a new hobby or party room or an office, the walls must be durably dry in order to turn a basement into a room where you can feel at home. This calls for reliable, highly functional waterproofing to protect the room against moisture from the surrounding soil. The most effective approach is to provide waterproofing where the wall comes into contact with water, i.e. on the exterior.
Precisely to meet this challenge, we offer three systems based on different technologies. The result is always the same –. Moisture is durably prevented from entering the building and the basement walls remain dry. Our waterproofing systems also provide protection against harmful radon gas from the soil. They also contribute to a healthy living environment.
The best cards for any challenge:
BUILDING WATERPROOFING WITH MINERAL SLURRIES AND THICK MINERAL COATINGS
The System PCI Barraseal Turbo is based on the flexible two-component reactive waterproofing membrane PCI Barraseal Turbo. This is a fast-setting mineral-based product that can be used in a variety of applications. It is especially well-suited for complex building shapes and rapid construction progress. The system is radon-tight.
Substrate preparation:
The existing substrate must be sound and free from cavities. Old, firmly adhering bitumen coatings must be cleaned.
1. Waterproofing/concave molding:
PCI Polyfix plus L – Quick-setting cement mortar for rapid repairs above and below ground
2. Primer/contact layer (optional):
PCI Gisogrund 404 – Wash primer for absorbent and non-absorbent substrates
3. Surface waterproofing (W1):
PCI Barraseal Turbo – Flexible two-component reactive waterproofing slurry for external basement walls, foundations and concrete elements
4. Insulation board adhesive:
PCI Barraseal Turbo – Flexible two-component reactive waterproofing slurry for external basement walls, foundations and concrete elements
5. Waterproofing of foundation wall:
PCI Barraseal Turbo – Flexible two-component reactive waterproofing slurry for external basement walls, foundations and concrete elements
One system –many benefits:
■ Maximum adhesion security – also on old bituminous coatings
■ Fast-setting – rainproof after about 4 hours; the trench can be backfilled after about 6 hours
■ Flexible crack bridging up to 2 mm
BUILDING WATERPROOFING WITH COLD-APPLIED SELF-ADHESIVE MEMBRANES
The main component of the System PCI BT 21 is the cold-applied self-adhesive waterproofing membrane PCI BT 21. This product consists of a two-layer tearproof special foil and a strongly adhesive bitumen-rubber waterproofing compound. Thanks to the use of a special primer, the system can also be applied safely at temperatures as low as -5°C. Basement waterproofing using a self-adhesive membrane is recommended for projects where large surface areas need to be covered in a limited time, as only one layer needs to be applied and it is not necessary to wait for products to dry. The System PCI BT 21 is radon-tight.
1. Primer:
PCI BT 26 – Water-dilutable bitumen-rubber emulsion as a primer under cold-applied self-adhesive membranes, strips and tapes, alternatively PCI BT 28 – solvent-based primer for cold-applied membranes, especially for low temperatures and damp substrates
2. Waterproofing:
PCI BT 45/PCI BT 46 – Internal/external corner, prefabricated PVC corners for waterproofing, foundations
3. Surface waterproofing (W1):
PCI BT 21 – Cold-applied self-adhesive waterproofing membrane
4. Waterproofing of bases and edges:
PCI BT 23 – Cold-applied self-adhesive waterproofing strips
5. Upper edge:
PCI BT 42 – Fixband B 100 / B 150, self-adhesive butyl sealing tape with nonwoven plastic backing on one side
6. Insulation board adhesive
PCI Pecimor DK – Bitumen adhesive for insulation boards on external basement walls and foundations
7. Waterproofing under walls (W4) and waterproofing of foundation walls (W4)
PCI Barraseal Turbo – Flexible two-component reactive waterproofing slurry for external basement walls, foundations and concrete elements
One system –many benefits:
■ Optimum adhesion and durable protection thanks to special adhesive compound
■ Optimum shaping properties – can be applied without creases and remains flexible even at low temperatures
■ The best immediate solution – defined layer thickness, high area performance, no drying times
BUILDING WATERPROOFING WITH POLYMER-MODIFIED THICK BITUMINOUS COATINGS (PMBC)
The System PCI Pecimor features tried and tested thick bituminous coating technology and ensures that buildings in contact with the soil are waterproofed in accordance with the applicable standards. All the requirements faced by a PMBC waterproofing system can be met with only two waterproofing products. Both PCI Pecimor 2K and PCI Pecimor 1K can be applied easily, with little force. They have been tested by independent test institutes and resist dissolving by soft rainwater.
In addition, waterproofing with PCI Pecimor 2K is radon-tight.
1 . Waterproofing under walls (W4) and waterproofing of foundation walls (W4):
PCI Barraseal Turbo – Flexible two-component reactive waterproofing slurry for external basement walls, foundations and concrete elements
2. Waterproofing against moisture from the back (optional):
PCI Barraseal – Mineral waterproofing slurry for basements, drinking water and wastewater areas
3. Waterproofing/concave molding:
PCI Polyfix plus L – Quick-setting cement mortar for rapid repairs above and below ground
4. Primer:
PCI Pecimor F – Bitumen primer for external basement walls and foundations, or alternatively
PCI Pecimor Betongrund – Special primer for external concrete basement walls
5. Waterproofing (W1, W2, W3):
PCI Pecimor 2K – Thick bituminous coating for external basement walls and foundations, or alternatively
PCI Pecimor 1K – Thick bituminous coating for external basement walls and foundations
6. Insulation board adhesive:
PCI Pecimor DK – Bituminous adhesive for insulation boards on external basement walls and foundations
One system –many benefits:
■ Easy product selection – all the requirements for the waterproofing of buildings using polymer-modified thick bituminous coatings can be met with only two PCI products
■ High area yield – good non-sag properties ensure even material application with the required layer thickness
■ Reliable application – the surface is already sealed after the first step
